FEATURES
PoE Features:
Support active IEEE 802.3af/at for new POE devices and static mode for traditional POE devices.
POE overload and short circuit protection, sensitive POE ports.
Layer 2 Features:
4K VLAN Table, 8K MAC table, QoS, port-isolation, link aggregation protocol, link-layer discovery protocol, spanning tree protocol.
DHCP server/client.
Security Features:
Access list (L2-L4), port-security.
Management:
Web-based management supports.
Support SNMP/RMON/TELNET/SSH.
Console port.
| Model No | SW-MNG-8GE2GSFP-8POE-V2 |
| Product description | Managed 8 Giga Ethernet Ports POE+ 2 Ten Giga SFP Ports |
| 10/100Mbps RJ45 Ports | NA |
| 10/100/1000Mbps RJ45 Ports | 8 |
| 10 GSFP Ports | 2 |
| Console Port | 1 |
| PoE Ports | 8 |
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z, IEEE802.3ad, IEEE802.3az, IEEE802.1q, IEEE802.1p, IEEE802.1s, IEEE802.1d, IEEE802.1w, IEEE802.1x, IEEE802.1ad, IEEE802.1ab, IEEE802.3af/at |
| Switching Fabric Capacity | 20Gbps |
| Mac Address Table | 8K |
| Buffer | 4.1Mb |
| Jumbo Frame | 10KByte |
| IEEE802.3af | √ |
| IEEE802.3at | √ |
| Power Supply | AC 100V-240V 50/60HZ |
| Operating Temperature | 0°C ~50°C |
| Max PoE Output Power |
140W |
| Housing |
Metal Rack Mount |
| Dimension |
280 x 179 x 44.5 mm |
