Features
- Provide 1channel AC 220V power input.
- Provide a PoE-unmanaged switch, 8GE ports + 2gigabit SFP ports, with an uninterruptible power supply.
- Built-in fiber tray, grounding row, etc.
- The box body adopts waterproof (protection level IP55), anti-rust) treatment, suitable for long-time outdoor use.
TECHNICAL SPECIFICATION
|
Model No. |
SW-UNG-8GE2GSFP-8POE-IND-WP |
|
Power Input |
AC 100-240V, 50/60Hz |
|
Consumption |
Self-consumption<15W, PoE output 115W max |
|
Downlink ports |
1~8 ports: 10/100/1000Base-T 30W PoE RJ45(IEEE802.3af/at) |
|
Reset key |
Short press restart, >5s press recovery to default |
|
Cable and distance |
Use cat5e/6, 100m max. |
|
Standard |
IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z,IEEE802.3az, IEEE802.3af & IEEE802.3at |
|
Switch fabric |
20Gbps |
|
Though put |
14.88Mpps |
|
Buffer |
12KB |
|
MAC address table |
4K |
|
Indicator |
Power: 1 *red ; Downlink 1~8: On RJ45 green LEDs indicate Link/Act, yellow LEDs indicate PoE Uplink9, 10: On RJ45 green LEDs indicate Link/Act |
|
Protection |
Surge: 6KV, standard: IEC61000-4-5 ESD: 6KV: contact 8KV: air, standard:IEC61000-4-2 |
|
SPD |
AC lightning arrester, 385v AC@20KA , 2p, – 40 ~ 70 oC, lower incoming line, dxh06-fcs / 2r40 |
|
Working temperature |
-20oC~65oC |
|
Storage temperature |
-40oC~85oC |
|
Humidity |
0~95%(No condensation) |
|
Dimension(L×W×H) |
280mm×200mm×260mm |
|
Material |
Metal |
|
Colour |
White |
|
Net-weight |
8Kg |
